Ideal balance of SWaP
Size:93.3mm x 49.5mm x 35mm
Weight:0.13 kg
Power:250mA @ 12VDC
Real-time video at the Speed of 5G. Stream Anywhere. Decide Faster.
The FireBird™ F-100 5G delivers the same proven video streaming performance of the original FireBird™ F-100, now with enhanced 5G connectivity, improved power efficiency, and USB 3.0 video input. It’s compact and purpose-built for video monitoring, drones, UAVs, USVs, and civilian and government surveillance applications that require fast setup, high mobility, and connectivity even in low-bandwidth and congested environments.
The FireBird™ F-100 5G comes pre-installed with FireLight™, our bandwidth efficient video encoding software, which enables real-time video streaming at high resolution, up to 30fps full HD. If the network bandwidth drops, it adjusts the video encoding automatically, down to as little as 1 kbps, while maintaining usable image quality. Whether deployed on static sites, drones, tactical vehicles, or embedded in soldier kits, this unit provides continuous operational visibility anywhere, under any network condition.
Built for High-Mobility Operations
Running Videosoft’s FireLight™ software, the FireBird™ F-100 5G enables real-time situational awareness by compressing and securely transmitting multiple video streams simultaneously. Each stream can be optimised for bandwidth, resolution, and latency in real-time, allowing mission commanders and operators to prioritise visibility from multiple angles without overwhelming the network.
With dimensions of 93.3mm x 49.5mm x 35mm and weighing just 0.13 kg, the FireBird™ F-100 5G is optimised for SWaP-constrained applications. It supports Ethernet and USB camera input, making it ideal for remote deployments, robotics, UAV integrations, and tactical use. With its ultra-low power draw, the FireBird™ F-100 5G enables fully autonomous battery-operated applications.
Real-Time Situational Awareness with 5G Resilience
Streaming over 5G cellular using the internal modem or via satellite or mesh radio networks using external modems, the FireBird™ F-100 5G provides flexible, secure real-time video transmission from the edge. Whether operating in contested environments or unpredictable network conditions, the device ensures continuity through adaptive video encoding, local failover recording, and automatic reconnection when the network is restored.
Seamless Streaming & Integration
Live streams and telemetry from the FireBird™ F-100 5G can be accessed remotely via Videosoft’s secure client apps on Windows, Android, or iOS, and also existing third-party video management systems (VMS) via ONVIF and RTSP protocols. Whether part of a CCTV system, a tactical soldier kit, mounted on a drone, or operating aboard a patrol boat, the FireBird™ F-100 5G connects seamlessly to industry-leading VMSs, ATAK, C2, and NATO ISR platforms.
Why Choose FireBird™ F-100 5G?
- Optimised Video Streaming: Enable real-time video surveillance over cellular, mesh, and satcom networks
- Small Yet Powerful: USB + GbE inputs, integrated 5G modem, low SWaP
- Next-Gen Performance: Plug and Play, easy to use, high reliability, and security
- Field-Proven: Trusted by industry, military, and security forces across multiple continents
- Fast Deployment: Simple setup gets you operational in minutes, not hours
- Mission Adaptable: Works seamlessly with third-party VMS and C2 applications
Why It Matters?
Real-time video can mean the difference between mission success and failure. FireBird™ F-100 5G enables:
- Faster tactical decision-making
- Safer remote operations
- Greater command visibility in high-risk zones
Get to know the FireBird™ F-100 5G Video Encoder
See how its robust features, tech specs, and SWaP-optimized design deliver reliable, real-time streaming performance in environments where network speed is limited and/or variable.
Frequently Asked Questions
What is the FireBird™ F-100 5G, and who is it designed for?
The FireBird™ F-100 5G is a next-generation, ultra-compact video encoder designed specifically for field deployments that require secure, real-time video streaming over 5G (with internal modem), satellite, mesh, or IP radio. Designed for edge-based operations where size, power, and weight are key factors, it’s trusted by defence, security, and first responder agencies for use in remote monitoring, UAVs, robotic systems, and soldier-worn kits.
How does the FireBird™ F-100 5G differ from the original FireBird™ F-100?
While both models share the same resillient architecture and FireLight™ video streaming software, the FireBird™ F-100 5G offers several upgrades: it includes built-in 5G cellular connectivity for faster and more flexible deployment; it supports USB 3.0 camera inputs for broader video device compatibility; it consumes less power, only about 3W and is lighter, making it even better suited for mobile or battery-operated missions.
Can the FireBird™ F-100 5G operate effectively in low-bandwidth or challenging environments?
Yes, and that’s where it truly excels. With FireLight™ adaptive video compression, it can deliver quality real-time video streams at bandwidths from just 1 kbps. Even when deployed in contested or bandwidth-restricted areas, the FireBird™ F-100 5G continues to function efficiently, recording video locally during dropouts and automatically reconnecting when connectivity is restored.
What types of cameras or sensors can be used with this device?
The FireBird™ F-100 5G supports both USB 3.0 and Ethernet (RJ45) video inputs, allowing operators to use a wide range of devices, from helmet-mounted cameras and EO/IR sensors to rugged thermal imagers, drone payloads, and any ONVIF/RTSP cameras. The flexibility to support multiple inputs provides teams with a broader range of video options from a single, compact encoder.
Is video transmission secured and compliant with military standards?
Absolutely. The FireBird™ F-100 5G uses AES-256 encryption and complies with FIPS and NDAA standards. All video, telemetry, and control data are fully encrypted during transmission, ensuring mission-critical intelligence remains tamper-proof and secure.
How power efficient is the FireBird™ F-100 5G, and why does it matter?
The unit consumes just 250mA at 12VDC, or roughly 3 watts, remarkably low for a tactical video encoder. This low draw extends operational runtime when using battery packs or portable power sources, eliminating the need for active cooling and making it ideal for lightweight deployments, such as concealments, soldier-worn kits, or UAV platforms.
Can it integrate into our current VMS or command-and-control system?
Yes. FireBird™ F-100 5G is designed to integrate seamlessly into existing ecosystems. It supports ONVIF and RTSP protocols, enabling compatibility with third-party video management systems through the bridge, and connects easily with ATAK, C2 platforms, and NATO-standard ISR tools. Remote access is also available through Videosoft’s secure client apps for Windows, Android, and iOS.
What happens to the footage if the network connection fails mid-stream?
No footage is lost. The FireBird™ F-100 5G includes edge-based local recording, meaning all video is stored onboard during connection loss. Once the network is re-established, it automatically resumes streaming and can deliver the recorded footage on demand, ensuring no gaps in situational awareness.
How quickly can it be deployed in the field?
Thanks to its plug-and-play design, the FireBird™ F-100 5G is fully operational within minutes. Connect your video source, power on the device, and it starts streaming, no complicated configuration or setup required. This makes it ideal for rapid deployment in high-pressure or time-sensitive operations.
Can I use it with Mesh Radios, BGAN terminals and other network equipment?
Yes. The FireBird™ F-100 5G supports mesh radio or satellite communications (satcom) integration and performs exceptionally well over BGAN and other mobile satellite systems. FireLight™ software optimizes the video for these links, keeping the live streams stable and viewable even on narrow satellite channels.
